Fiber Distribution Box OPT-F308 is used as a termination point for the feeder cable to connect with drop cable in FTTX communication network system.
Fiber Distribution Box OPT-F308 intergtates fiber splicing, splitting, distribution, storage and cable connection in one unit. Meanwhile, it provides solid protection and management for the FTTX network building.
Share:
| Model | OPT-F308 |
| Protection level | IP66 |
| Dimension | 358mm×240mm×92mm |
| Outter carton size | 770×415×470mm |
| Capacity of FOSC ratio | Bunchy:60(cores) 1 × 1:8 or 2 × 1:4 |
| Inner carton size | 405×245×110mm |
| Cable Capacity,Branch | 2 pieces ∅12mm,2 pieces ∅14mm |
| Diameter of cable | ∅7mm～∅14mm |
| Number of packing | 12pcs/ctn |
| Cable Capacity, Drop | 8 pieces ,2mm×3mm ,5mm, 5mm×3mm,5.2mm |
| Weight | 1.7kg/pcs |
