Fiber Distribution Box OPT-GTS-12-1 is used as a termination point for the feeder cable to connect with drop cable in FTTX communication network system.
Fiber Distribution Box OPT-GTS-12-1 intergtates fiber splicing, splitting, distribution, storage and cable connection in one unit. Meanwhile, it provides solid protection and management for the FTTX network building.
Share:
| Model | OPT-GTS-12-1 |
| Protection level | IP68 |
| Dimension | 262mm×235mm×96mm |
| Outter carton size | 555×500×360mm |
| Capacity of FOSC ratio: | Bunchy:84(cores) 1 ×1:4 and 1 × 1:8 |
| Inner carton size | 267×500×110mm |
| Hardened Adpter | 13 |
| Number of packing | 12 pcs/ctn |
| Cable Capacity, Drop | 2mm×3mm , 5mm， 5mm×3mm， 5.2mm |
| Weight | 1.7kg/pcs |
