Fiber termination box is used as a termination point for the feeder cable to connect with drop cable in FTTX communication network system.
4 port fiber termination box intergtates fiber splicing, splitting, distribution, storage and cable connection in one unit. Meanwhile, it provides solid protection and management for the FTTX network building.
Share:
Wall mounting and pole mounting installtion
FTTH pre-installation and filed installation
5-10mm cable ports suitable for 2x3mm indoor FTTH drop cable and outdoor figure 8 FTTH self-supporting drop cable.
Specifications
Fiber Termination Box OPT-307B FTTH 4 core
| Material | Strengthen ABS |
| Size,mm | 100*80*30 |
| Max Capacity | Splice 4 Fibers(1trays,4 core/tray) |
| Qty of Adapter | 4 pcs of SC(max) |
| Weight,kg | 0.1 |
| Colour | White |
| Ports | 4 ports |
Standard Accessories
