400G OSFP SR8 transceiver modules are designed for use in 400 Gigabit Ethernet links on up to 100m of Multimode fiber. They are compliant with the OSFP MSA and IEEE 802.3cd/cm.The optical transceiver is RoHS compliant.
Share:
Hot-pluggable OSFP form factor
Supports 425Gb/s aggregate bit rate
Power dissipation <10W
Commercial case temperature range of 0°C to 70°C
Single 3.3V power supply
Maximum link length of 100m on Multi Mode Fiber (MMF)
Aligned with IEEE 802.3cd/cm
8x50G PAM4 VCSEL-based 850nm transmitter
8x50G PAM4 retimed 400GAUI-8 electrical interface
MPO-16 receptacles
I2C management interface
RoHS compliant
DATACOM
Specification
| Data Rate | 425Gb/s |
| Case Temperature | 0~70℃ |
| Transmitter | Vcsel |
| Wavelength | 850nm |
| Power consumption（Max） | 10W |
| Distance | 100m |
| Voltage Supply | 3.3V |
| Receiver | PIN |
| Connector | MPO-16 |
