The SFP-1000BASE-T is a multi-rate SFP copper transceiver with an RJ45 interface, supporting 10/100/1000Mbps auto-negotiation. It delivers reliable transmission up to 100m over Cat5e/Cat6/Cat7 twisted pair cables, compliant with MSA and IEEE standards. Hot-swappable and widely compatible with mainstream network devices, it’s perfect for short-distance connectivity in enterprise LANs, small data centers, and office networks.
Share:
| Technical Parameters | Detailed Specifications |
|---|---|
| Product Model | SFP-1000BASE-T |
| Form Factor | SFP (Hot-swappable) |
| Interface Type | RJ-45 |
| Transmission Rate | 10/100/1000Mbps (auto-negotiation supported) |
| Transmission Distance | 100m over Cat5e/Cat6/Cat7 twisted pair cables |
| Cable Type | Cat5e/Cat6/Cat7 twisted pair |
| Power Consumption | ≤1.2W (Typical low-power operation) |
| Operating Temperature | 0℃~70℃ (Commercial grade) |
| Protocol Compatibility | Compliant with IEEE 802.3ab, SFP MSA standards |
| Special Features | Auto-MDI/MDI-X, EMC compliant, DDM/DOM diagnostic function supported |
